APPLICATION

Multipurpose hose, specifically designed to convey pharmaceutical, cosmetic and chemical substances.
Especially suitable for application in pharmaceutical environments and production processes requiring the use of non-contaminating, inert materials.

CONSTRUCTION

TUBE
PFA (Perfluoroalkoxy Polymer), white colour, fully fluorinated, mirror-smooth. Odourless and tasteless.
Compliance: USP Class VI, 3A, FDA Standards, D.M. 21/03/73 and following amendments, Regulation EU n. 10/2011, ISO 10993-4, -10, -11, non-cytotoxic according to ISO 10993-Part 5.
REINFORCEMENT
High strength plies of synthetic cord and embedded steel helix wire.
Two copper wires are embedded.
COVER
Marble finish (UPE), black and white, patented, smooth, resistant to abrasion, ozone and ageing.
Antistatic: Electrical resistance R <= 106 ohm
The special marble finish with a low coefficient of friction complies with FDA Standards, odourless and tasteless. The cover does not stain the contact surfaces.

TEMPERATURE RANGE

From -40°C to +130°C depending on the fluids conveyed and the application. In case of dynamic application: from +10°C to +40°C.
Sterilization up to +150°C for max. 30 minutes.

Specifications
